Plated Truss
Slant Nail Truss Hangers
MUS / HUS
Reference Series: MUS, HUS
The MUS / HUS hanger series offers double shear nailing. MiTek’s raised dimple allows for 30° to 45° nailing through the joist into header, resulting in higher loads and less nailing.
Materials: MUS – 18 gauge; HUS – 16 gauge
Finish: G90 galvanizing
Code Reports:
View Code Report Table
Installation
- Use all specified fasteners.
- Joist nails must be driven at a 30° to 45° angle through the joist or truss into the header to achieve listed loads. Standard length “double shear” nails must be used to achieve listed load values.
Need Help or Have a Question? Contact Customer Service or Call 800-328-5934
MUS Slant Nail Face Mount Joist Hanger
Option Details:
Code Report Table
3-View Product Drawings
| MiTek Stock # | Download or View Files | |||
|---|---|---|---|---|
| HUS175 | DWG | DXF | View Image | |
| HUS177 | DWG | DXF | View Image | |
| HUS179 | DWG | DXF | View Image | |
| HUS210 | DWG | DXF | View Image | |
| HUS210-2 | DWG | DXF | View Image | |
| HUS26 | DWG | DXF | View Image | |
| HUS26-2 | DWG | DXF | View Image | |
| HUS28 | DWG | DXF | View Image | |
| HUS28-2 | DWG | DXF | View Image | |
| HUS410 | DWG | DXF | View Image | |
| HUS46 | DWG | DXF | View Image | |
| HUS48 | DWG | DXF | View Image | |
