STAND-ALONE CONVEYOR

Transport large assemblies to the next stage in the building process.

Free Consultation
Features

EASILY TRANSFER TRUSSES

  • Reduces time spent on material handling tasks, increasing the productivity of your plant.
  • Every second roller is powered to ensure smooth movement of the truss.
  • Integrates with MiTek stackers and Finish Rollers to be fully automated if desired.
Play Icon

Stand-Alone Conveyor Overview Video

Specifications

OVERVIEW

The Stand-Alone Conveyors allow you to easily transfer trusses from your truss assembly areas to the Finish Roller, and from the Finish Roller to truss stackers. The conveyor system can greatly reduce time spent on material handling and increase the productivity of your plant. They are completely configurable to your workflow and footprint.



PHYSICAL DATA
Components1 roller assembly consists of roller and legs. Every other roller has a motor attached.
Dimensions4-1/2″ OD x 14′ long (see Options)
Motor1/2 hp (see Options)
PERFORMANCE DATA
Rotation Speed100 ft per minute
Min. Truss DimensionsThe space between conveyor rollers is min. length
Max. Truss DimensionsLength is unlimited; width of finishing press throat determines max. truss height
HMIPushbutton station
ELECTRICAL
Electrical Specs208/230/480/575 VAC, 60 Hz, 3-phase
415 VAC 60 Hz, 3-phase

Safety Data

  • Pushbutton E-stop
  • Bilingual or ISO safety labels
  • Safety compliance: UL (panels), OSHA

Options

  • Optional lengths: 3′, 4′, 6′, 16′
  • Conveyor in parking area to stack trusses shorter than 10′
  • Interlocks to integrate with conveyor and finishing press

Download the Full Spec Sheet

Download PDF
