Truss and Rafter Tiedowns

Hurricane Retrofit Connector


Reference Series: HM9KT
Designed as a retrofit connector for trusses installed on top plates. Can also be used as a holdown for a roof or floor system.
Materials: 18 gauge
Finish: G90 galvanizing
Code Reports: View Code Report Table


  • Use all specified fasteners.
  • Concrete screws are not supplied with RT16M connector.
  • Install concrete screws in lower two holes for Single Top Plate or Conventional Raised Foundation or Modular Home Installations.
  • Moisture barrier may be required.

Need Help or Have a Question? Contact Customer Service or Call 800-328-5934

Code Report Table


High Wind Drawings

MiTek Stock # Download or View Files
Bond/Tie Beam to TrussDWGDXFPDFView Image
