Concrete and Masonry
Universal Masonry Hangers
Reference Series: MBHU
A versatile solution for hanging beams from masonry walls. Face mount design allows hanger to be used with beam heights from 16" to 24". Available in a variety of widths for solid sawn, glulam, or engineered lumber beams.
Materials: 3 gauge
Code Reports: View Code Report Table
ResourcesMiTek Product Catalog
- Use all specified fasteners.
- Fully grouted and reinforced concrete block or cast-in-place concrete with a minimum of (1) #5 rebar continuous to footing with standard hook at bolt locations.
- Minimum joist width is 3-1/2″.
